Wuxi Tuanjiuhe Technology Co., Ltd. is a professional high-tech enterprise specializing in the R&D, production and sale of intelligent color sorters.
METKEY Salt Color Sorting Machine detection system is able to detect minimum differences in color and shade, with an optical resolution of 0.1mm.
Light or dark grey impurities, such as anhydrite, or with light orange and brownish shade, such as sulfur or inert or organic parts, are perfectly detected and sorted with the highest efficiency.
The possibility to foresee a simultaneous reject resort allows to recover good product rejected during the sorting phase, due to the high operating speed.
METKEY Salt Color Sorting Machine grants quality and hygiene safety when sorted salt is destined to food and non-food consumption.
| Model |
MSCS1S |
MSCS2S |
MSCS3S |
MSCS5S |
MSCS7S |
MSCS8S |
|
Executing Unit |
64 |
128 |
192 |
320 |
448 |
512 |
|
Throughout(t/h) |
0.5~3 |
1~4 |
2~6 |
5~10 |
9~17 |
11~20 |
|
Voltage(V) |
110~250V |
110~250V |
110~250V |
110~250V |
110~250V |
110~250V |
|
Power(kW) |
1 |
1.4 |
1.8 |
2.6 |
3.5 |
4 |
|
Weight(kg) |
210 |
350 |
600 |
880 |
1150 |
1250 |
|
Dimension(L*W*H/mm) |
960*1630*2050 |
1340*1630*2050 |
1610*1630*2050 |
2225*1630*2050 |
2980*1630*2050 |
3068*1630*2056 |
|
Sorting accuracy(%) |
≥99.99 |
≥99.99 |
≥99.99 |
≥99.99 |
≥99.99 |
≥99.99 |
|
Rejection rate |
≥10:1 |
≥10:1 |
≥10:1 |
≥10:1 |
≥10:1 |
≥8:1 |
|
Air consumption(L/min) |
400~88 |
600~100 |
800~1600 |
1300~2200 |
1800~3600 |
2200~4000 |
| Machine feature | ||
|
Key Components |
15''LCD Touch Pannel |
● |
|
True Color Camera |
● |
|
|
HD CCD Sensor |
● |
|
|
InGaAs Infrared Sensor |
○ |
|
|
Stainless Steel Ejector |
● |
|
|
RGB LED Lighting |
● |
|
|
SMC Pneumatic System |
● |
|
|
Sorting Solutions |
Sniper Sorting Solution |
● |
|
RGB+SHAPE Sorting |
● |
|
|
InGaAs Infrared Sorting |
○ |
|
|
Service life |
Ejector |
>10 Billion times |
|
LED |
>50000 hours |
|
|
Power Supply |
>50000 hours |
|
|
Intelligent System |
Smart Sorting Mode |
● |
|
Remote Control |
● |
|
|
Auto Self-Diagnosis |
● |
|
|
Program Backup |
● |
|
* High resolution special camera with pixile 5400 elements,high reliability,long life and maintenance free LED light source;
* Efficient and stable software system,intelligent algorism,user friendly interface;
* High reliability ejectors,key parts from Japan,life time over 10 billion times;
* Better sorting accuracy,lower carryover,and bigger production capacity;
* Super identification and rejection for tiny bad spot and micro impurities;
* Good at sorting salt of all kinds.
