Three Layer Optical Tea Color Sorter Features:

1. Using high-definition color CCD camera image acquisition system, to achieve material(RGB)red, green and blue three color information acquiring, depth recognition tiny fine color sorter can choose other impurities

2. Removes color defects and foreign material

3. Excellent value for money

4. Powerful software operation platform, easy to learn, simple and convenient to operate.

5. The application of air-cooled system has solved the problems of high temperature, heavy energy loss and short service life-all of which were caused by longtime utilization of an LED light source,ensuring the durability of an LED light source under a constant temperature

6. Offers simultaneous sorting, discolor sorting, reverse sorting and transparent sorting

7. Dedicated after sales support available

8. High-brightness and long-service-life LED light

Quick Detail:

Model	MTCS0030
Capacity(kg/h)	<500
Accuracy	97%
Voltage	220V50HZ
Power	3.2-4 KW
Weight(kg)	1700
Dimension	2530*2445*1805mm

Three Layer Optical Tea Color Sorter Description:

Color selection benefits , value for money

1. Big Data
Create an open mass database, storage unlimited amount of integrated wide-ranging material selection solution platform, to achieve a multi-selection, one machine multi-use, single machine can simultaneously complete the second selection, three selection, four selection, reduce the out-of-bounds ratio, single machine can be applied to black tea, green tea, green tea, rock tea, white mill and other wide-ranging uses, to maximize the value of product applications for customers, Share the convenience and business value of the big data era.

2 , intelligent magnetically controlled high-frequency solenoid valve
Self-developed color selection of smart magnetically controlled high-frequency solenoid valve, to create a leading smart lever flexible back-position technology to replace the traditional air pressure back function, air flow no leakage, no leakage; 70% , saves about the gas consumption 20% Apply new high anti-wear materials to ensure the use of life-long matching equipment, to create the best output benefits.

Color selection , Extreme Intelligence

1. Cloud Connect System
The technology platform of China Science and Technology Cloud Service can be used in real-time remote control, operation and maintenance, software upgrade, light source, electrical, mechanical and proofreading problem diagnosis and resolution, product online operation monitoring, data collection, online guidance, to provide real-time, barrier-free, intimate full-time active online tracking services.

2 . one-click smart operating system
Free choice, self-defined material color, shape, size, defective area, determine the object of culling, one-click intelligent self-control technology, automatically judge and accurately match the optimal selection scheme, according to the selection law of independent operation, intelligent identification, intelligent sorting.

3. Visual intelligent image acquisition system
Ultra-colorful in HD CCD Sensors and ultra-wide angle low distortion special lens, visual dynamic image capture system, real-time on-screen display material capture images, to achieve online dynamic information acquisition, selection quality detection, data intelligent analysis, can freely select and store the most preferred solution.

Color selection effect, trend to the extreme

1. autonomous primary computing and super-brain intelligence recognition
Powerful independent original computing processing technology and multi-dimensional multi-space large-scale operation, fusion super-brain intelligent recognition, the use of image recognition machine learning algorithm, correct and improve the image acquisition process, optical error cause of distortion, distortion, color selection adaptive operation, to meet the requirements of high fine selection.
2 . light source intelligent control dimming system
Advanced digital poleless automatic dimming technology, according to the material selection requirements and environmental changes automatically match the best brightness, fully guarantee color selection effect.
3. Independent sorting mode
One, two layers, you can set color selection or shape selection independently or independently + Color selection of any combination mode, three layers provide a selection of mode schemes. Different needs, free combination, any optional.
4. V Type sorting structure
Pre-selection box can be sorted after the scrap, can be to the rear sorting box for sorting, a sort to complete the finished product and net terrier, color selection accuracy is higher, damage rate is lower, more convenient operation.

Three Layer Optical Tea Color Sorter Applications:

The raw material could be blue tea, green tea, tieguanyin to recognize the color and quality.
