NIR Seed Color Sorter

NIR Intelligent Special Purpose Seed Color Sorter
Infrared Seed Sorting Machiner has a solution for sorting pumpkin and sunflower seeds. Our Infrared Seed Sorting Machine detects and rejects discoloration, sclerotia and all types of foreign material.
* Increased yield
* Reduced labor requirements
* Increased throughput
* Consistent quality
* Our sorting solutions boost throughput and availability while at the same time increasing yield, quality and food safety.

Direct supply from the manufacturer: Order phone：+86-18012365661; E-mail：alexzhang@metkeycolorsorter.com

Detail

Infrared Seed Sorting Machine Technical Parameters

Model	Channel	Throughput（T/h）	Carryover (bad: good)）	Accuracy（%）	Voltage(v/Hz)	Power(Kw)	Weight(Kg)	Dimensions(mm)
NSM1-A	64	0.5-3	＞10:1	≥99.99%	AC220V/50HZ	0.3~0.5	240	974.21550.91399
NSM3-A	192	1.5-9	＞10:1	≥99.99%	AC220V/50HZ	0.4-0.65	500	155417071827.9
NSM4-A	256	2-12	＞10:1	≥99.99%	AC220V/50HZ	0.7-1.1	800	186917071827.9
NSM5-A	320	2.5-15	＞10:1	≥99.99%	AC220V/50HZ	0.7-1.1	1000	218417071827.9
NSM6-A	384	3-18	＞10:1	≥99.99%	AC220V/50HZ	1.1-1.9	1100	2499.217071827.9
NSM7-A	448	3.5-21	＞10:1	≥99.99%	AC220V/50HZ	1.1~1.9	1350	2814.21706.71839.9
NSM8-A	512	4-25	＞10:1	≥99.99%	AC220V/50HZ	1.3-2.2	1500	31291709.91827.9
NSM10-A	640	5-30	＞10:1	≥99.99%	AC220V/50HZ	1.4-2.3	1750	3759.21709.91827.9
NSM12-A	768	6-35	＞10:1	≥99.99%	AC220V/50HZ	1.4-2.3	1900	43891709.91827.9

Infrared Seed Sorting Machine Technical Characteristics

1. High-precision image acquisition system
The international cutting-edge industry-specific 5400*3*12K full-color high-speed line scanning imaging CCD sensor can provide up to 190 million pixels of high-definition images per second. The color selection lens tailored by top international suppliers accurately recognizes 0.04MM fine lesions. , to meet the high-end color selection requirements of pin point, blackhead simultaneous sorting, and separate sorting.

2. Big data
Create an open mass database, store unlimited integration of a wide range of material selection solution platform, achieve one machine multiple selection, one machine multi-purpose, single machine can complete two, three, four selection at the same time, reduce the ratio of take-out, stand-alone can be applied to rice Widespread use of miscellaneous grains, cash crops, etc., to maximize product application value for customers, sharing the convenience and commercial value of the era of big data.

3. Multi-core parallel processing system
Adopting the new multi-core parallel processing system, the color selection, shape selection and intelligent selection scheme are flexibly matched and synchronized, and the foreign object precise recognition algorithm is combined to provide a more flexible sorting and combination scheme, and the color selection precision is higher.

Examples of Sorting

Coriander Seed Sorting Result

Infrared Seed Sorting Machine Advantage

1. Remote control function

Using Internet + technology, with the mobile phone APP smart color selection butler, to achieve remote control of the machine, as well as real-time online diagnostics.

2. Kernel separation function

Using multi-spectral fusion technology, the visible light and infrared light can be reasonably matched to perfectly separate the shells of the gourd seed and pumpkin seed kernel.

3. Visualization function

The visualization function is used to clearly preview the color selection effect, and the color selection effect corresponding to the current parameter is displayed in real time, helping the operator to adjust the parameter to the optimal value.
