Wuxi Tuanjiuhe Technology Co., Ltd. is a professional high-tech enterprise specializing in the R&D, production and sale of intelligent color sorters.
| Model |
MVS640B |
MVS1280B |
MVS1600B |
|
Output（t/h） |
1.2-6 |
2.5-12 |
3.2-15 |
|
Carryover (bad: good) |
≥15：1 |
≥15：1 |
≥15：1 |
|
Accuracy (%) |
≥99 |
≥99 |
≥99 |
|
Voltage (V/Hz) |
220V/50HZ |
220V/50HZ |
220V/50HZ |
|
Power (Kw) |
1.0-1.3 |
1.6-2.6 |
2.0-3.3 |
|
Air pressure (Mpa) |
0.6-1.0 |
0.6-1.0 |
0.6-1.0 |
|
Consumption (L/min) |
＜1024 |
＜2048 |
＜2560 |
|
Weight (Kg) |
1000 |
1360 |
1900 |
|
Dimensions (mm) |
3108*993*1680 |
3108*1986*1680 |
3108*2306*1680 |
A bucket with a discharging system, no need to replace the hopper can be arranged flexibly. Scrap, finished all can check scheme.
Automatic fault protection and notification functions can stop the equipment and inform the operator of the danger before it is damaged, more effectively.
The sorting machine can be equipped with imported dedicated solenoid valves or self-made high frequency solenoid valves.
