Wuxi Tuanjiuhe Technology Co., Ltd. is a professional high-tech enterprise specializing in the R&D, production and sale of intelligent color sorters.
The drying of cereal, rice, wheat, grain, corn, cottonseed etc. To ensure that the moisture content of rice, wheat and seed is higher that the national storage standard.
The dryer within 50 Tons capacity is designed without screw conveyor , efficiently solve the problem of crushing materials,
| Model |
5HPX-15 |
5HPX-20 |
5HPX-30 |
5HPX-30B |
5HPX-35 |
|
|
Loading capacity(kg) |
Paddy |
3,000~15,000 |
3,000~20,000 |
4,000~30,000 |
4,000~30,000 |
5,000~35,000 |
|
|
Corn |
3,800~18,500 |
3,800~24,600 |
5,000~36,400 |
5,000~36,400 |
6,000~42,000 |
|
Dimension L*W*H (mm) |
4321*2583*10000 |
4600*3263*10500 |
4600*3260*12700 |
4600*3570*12700 |
5712*5000*12400 |
|
|
Net Weight |
3,000 |
4,200 |
5,500 |
6,500 |
8,000 |
|
|
Heat Source |
Biomass Furnace/Gas Burner/Diesel Burner |
|||||
|
Power Consumption (kw) |
9.95 |
10.6 |
15.45 |
21.7 |
19.7 |
|
|
Input Voltage |
3 Phase 220V/380V,50Hz |
|||||
|
Husk Furnace |
Type |
Indirect |
||||
|
|
Ignition |
Manual |
||||
|
Function |
Loading |
50~60(approx) |
50~60(approx) |
60~70(approx) |
60~70(approx) |
60~70(approx) |
|
|
Discharge |
50~60(approx) |
50~60(approx) |
60~70(approx) |
60~70(approx) |
60~70(approx) |
|
|
Drying Rate |
0.5-1.2 %/h |
0.5-1.2 %/h |
0.6-1.2 %/h |
0.6-1.4 %/h |
0.5-1.2 %/h |
|
Standard Devices |
Online moisture meter, Conveyor ,Discharge system, Buffer system, Elevator ,Suction fan, Temperature sensor |
|||||
|
Safety Devices |
Overload device, Temperature control device, Control fuse, Leakage protection device, Air pressure switch |
|||||
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.
