Use METKEY Large Capacity Rice Dryer Paddy Drying Machine to Beat Rising Fuel Prices, Save Drying Cost !
Use renewable biomass fuels to dry paddy, wheat, corn and soya bean etc. lowest drying cost, best grain quality after drying.
|
Model |
HG10 |
HG12 |
HG15 |
||
|
Loading capacity (kg) |
Paddy (kg) |
2300 ~ 10000 |
2300 ~ 12000 |
2300 ~ 15000 |
|
|
Wheat (kg) |
2700 ~ 12100 |
2700 ~ 14500 |
2700 ~ 18200 |
||
|
Performance |
Feed Time |
Paddy |
45 ~ 55 |
50 ~ 60 |
70 ~ 80 |
|
Wheat |
40 ~ 50 |
50 ~ 60 |
70 ~ 80 |
||
|
Outlet Time |
Paddy |
40 ~ 50 |
45 ~ 55 |
65 ~ 75 |
|
|
Wheat |
35 ~ 45 |
45 ~ 55 |
65 ~ 75 |
||
|
Drying capacity (kg.) |
7800 |
8000 |
9000 |
||
|
Internal volume (m³) |
18.53 |
23.96 |
27.18 |
||
|
Outside dimension L*W*H (mm) |
4828*2492*7436 |
4828*2492*8750 |
4828*2492*9556 |
||
|
Packing dimension L*W*H (mm) |
2100*2080*6602 |
2100*2080*7916 |
2100*2080*8722 |
||
|
Net weight (kg) |
2700 |
2800 |
3000 |
||
|
Power (Kw) (Excluding Burner) |
6.8 |
6.8 |
6.8 |
||
|
Standard Devices |
Online computerized moisture meter, Grain temperature sensor, Fault sensor etc |
||||
|
Safety Devices |
Full load alarm device, Thermal relay, Temperature controller, Abnormal combustion sensor, Overload protection device, Earth leakage protection device. |
||||
|
Centrifugal |
Rated air volume(m³) |
6677 ~ 13353 |
|||
|
Air outlet diameter(mm) |
600 |
||||
|
RPM |
1450 |
||||
Drying rate list is for reference only. Actual data will differ by ambient temperature, relative humidity, grain variety, hot air temperature, moisture rate before and after drying.
